GE Logiq P3 Ultrasound System MST Board 5400902
GE Logiq P3 Ultrasound System MST Board 5400902
About GE Logiq P3 MST Board Information
- Main System Tray Board: In ultrasound equipment, the system tray board is usually an integrated circuit board or module that is responsible for connecting and controlling various hardware components inside the equipment, including but not limited to ultrasound parts and imaging parts. It may contain key components such as processors, memory, interface circuits, etc., which are used to realize data transmission, processing and display.
- Association with ultrasound and imaging
1. Association with ultrasound:
The system tray board may be connected to the ultrasonic transducer (probe) through an interface circuit, which is responsible for converting electrical signals into ultrasonic signals and sending them to the probe, and also receiving ultrasonic echo signals sent back by the probe.
It may also contain circuits for controlling ultrasonic transmission and reception, such as transmitting circuits and receiving circuits, to ensure stable transmission and efficient reception of ultrasonic signals.
2. Association with imaging:
The processor on the system tray board may be responsible for processing the received ultrasonic echo signals and converting them into digital image data.
It works closely with the image processor to send the processed image data to the display for display.
In addition, the system tray board may also include an interface connected to the storage system for storing ultrasound images and data in hard drives, removable storage media, or network storage devices, etc.
Components - May include:
Processor: responsible for data processing and calculation.
Memory: used to temporarily store data and programs.
Interface circuit: including interfaces connected to probes, displays, storage systems, etc.
Control circuit: used to control the transmission and reception of ultrasound, as well as the processing and display of images.
Wide variety of probes/parts, over 1000 pcs in stock, involved in popular brands and systems(GE, Hitachi Aloka,Philips,Siemens,Toshiba,Esaote......)
Experienced & specialize after-fix technical support team.
Other GE related ultrasonic components we can offer:
Brand | System | Description |
GE | Logiq P3 | Probe Connector board 3PP 5314411-3 |
GE | Logiq P3 | Numeric Keyboard 5315106 |
GE | Logiq A5 | Syscon board 5177270 |
GE | Logiq V3 | MST PWA board 5599379 |
GE | Logiq V5 | monitor |
GE | Logiq P5 | APS High voltage power supply 5140505/ 5166108/5329667 |
GE | Logiq P5 | SYSCONPM 5177848-3 |
GE | Logiq P5/P6 | Trackball TAS4725N /5144543-3 |
GE | Logiq P5 | CTX Assy(Launch board) P\N :5140493 Rev 2 |
GE | Logiq P5 | PMSOM board(P/N:5178410-2) |
GE | Logiq P5/P6 | contral board(P/N: 5144536/5252253) |
