GE VIVID E9 GRX Board GA200105
About GE VIVID E9 GRX
1. Functions and Roles
Receiving Ultrasonic Signals: GRX Board is responsible for receiving ultrasonic signals captured by the probe. After being reflected by body tissues, these signals are received by the probe and transmitted to GRX Board for processing.
Signal Processing: The received ultrasonic signals are amplified, filtered, digitized, and processed on the GRX Board for subsequent image reconstruction and display.
Collaborative Work: GRX Board works with other boards such as the transmitter board (GTX) and the interface board (RELAY) to achieve the generation of ultrasonic images. The GTX board is responsible for loading the encoded high voltage and controlling the emission of sound waves, while the GRX board is responsible for receiving these sound wave signals and processing them.
2. Technical Features
High-speed processing capability: GE Vivid E9 uses the AVA high-speed platform, which enables GRX Board to process a large number of ultrasonic signals and ensure the real-time and clarity of images.
High-resolution imaging: Through advanced signal processing technology, GRX Board can generate high-resolution ultrasonic images, which helps doctors make more accurate diagnoses.
Flexible Configuration: In the GE Vivid E9 system, the number and configuration of GRX Boards can be adjusted as needed to meet different examination needs.
3. Troubleshooting and repair
Fault phenomenon: When the ultrasound image is disturbed, blurred or abnormal, it may be that the GRX Board or its related connections are faulty.
Troubleshooting steps:
Check whether the GRX Board and its connection cables are intact.
Use the substitution method to replace the GRX Board of the faulty device with the GRX Board of a normal device to determine whether the GRX Board itself is faulty.
If it is determined that the GRX Board is faulty, you need to contact professional maintenance personnel for replacement or repair.
