GE Logiq E9 Ultrasound System MRX Board 5393908
GE Logiq E9 Ultrasound System MRX Board 5393908
About GE Logiq E9 MRX Board
I. Functions and roles of MRX Board
MRX Board is a key component of GE Logiq E9 ultrasonic diagnostic instrument, which combines multiple functional modules such as DRX, GRX and GFI, and plays an important role in receiving and processing signals. These capabilities make the MRX Board play a vital role in the ultrasound imaging process, ensuring image quality and diagnostic accuracy.
2. Maintenance and replacement of MRX Board
Maintenance needs:
When the MRX Board fails, it may cause the ultrasound diagnostic instrument to not work properly or the image quality to decrease. At this point, professional repair or replacement is required.
Repairing or replacing an MRX Board usually needs to be done by a trained technician or a manufacturer-authorized repair center.
Maintenance case:
In some repair cases, the technician may troubleshoot the problem by replacing the MRX Board that was tested OK. However, if the fault persists after replacement, you need to further examine other possible points of failure.
Budget and cost:
The cost of repairing or replacing an MRX Board can vary depending on a number of factors, including the specific cause of the failure, the parts that need to be replaced, and the cost of repair services.
According to the inquiry announcement of the repair project of MRX board of a GE LOGIQ E9 ultrasonic diagnostic instrument, the budget for replacing one MRX board matching GE LOGIQ E9 ultrasonic diagnostic instrument is RMB 50,000. This is for reference only and actual costs may vary depending on the circumstances.
3. Troubleshooting of MRX Board
In the event of a system error or image quality issue with the GE Logiq E9 ultrasound diagnostic device, technicians may troubleshoot the device by following the following steps:
Check the power supply: First check whether the power supply is normal and eliminate the possibility of power failure.
Check MRX Board: If the power supply is normal, then check whether the MRX Board is working properly. This typically includes checking the MRX Board's wiring, signal transmission, and compatibility with other components.
Check other components: If the MRX Board is normal, but the problem persists, the technician may further check other possible points of failure, such as GTX board, PD board, etc.
Other GE related ultrasonic components we can offer:
Brand | System | Description | Part Number |
GE | Logiq E9/vivid E9 | GTX | GA200726 |
GE | Logiq E9 | MRX Board | 5393908/5393912 |
GE | Logiq E9/vivid E9 | GFI2 | 5161631 |
GE | Logiq E9 | BEP Power Supply | 5393800-3/5166790-2 |
GE | Voluson E6/Voluson E8 | RSR | KTI301394-2/KTI196357 |
GE | Voluson E6/Voluson E8 | RST | KTI301148 |
GE | Voluson E6/E8/E10 | RSX | KTZ303054 /KTI303054 |
GE | Voluson E6/E8/E10 | RFM201 FE mainboard | KTZ303916 |
GE | Voluson E6/E8/E10 | RFM221 FE mainboard | KTZ303915 |
GE | Voluson E6/Voluson E8 | RFI/ RFI21b Board | KTI300614/KTI302197-6 |
GE | Voluson S6/S8/P8 | BF64 | 5396937-2 |
GE | Voluson S6/S8/P8 | BF128 | 5338209-2 |
GE | Voluson S6/S8/P8 | CPS Power supply | 5393431 |
GE | Voluson S6/S8/P8 | RFS board | 5364098-2/5364098-3 |
GE | Voluson S6/S10/P8 | BF192 board | 5357234 |
