GE Logiq C5 Motherboard Ultrasound Spare Board 5351687
GE Logiq C5 Motherboard-5351687
About GE Logiq C5
1. Composition of GE Logiq9 color ultrasound
The GE Logiq9 color ultrasound diagnostic system consists of a power module, a computer (PC), a front-end circuit board box, a display and a control panel. Among them, the computer is loaded with the Windows XP operating system and corresponding applications. It is the heart of the whole machine, responsible for controlling and coordinating the work of various parts of the host, and analyzing and calculating the signals sent from the front end to form a video signal output to the display to obtain the ultrasound image you see
2. Working principle of GE Logiq9 color ultrasound
The working principle of this system is based on the combination of a computer and a scanner with a probe. The machine startup (power-on) process is the same as that of GE Logiq9, and the independent computer is the first component of the machine to start working
3. Analysis of GE Logiq9 color ultrasound failure cases
The machine cannot start: Possible reasons include ATX power supply problems or computer motherboard failures. For example, the case mentioned in the article is caused by leakage of the filter capacitor of the 12 V voltage
A blue screen interface appears after the machine starts: This is usually related to the Windows software and the computer hardware it dependscolor ultrasound on. Solving such problems may require checking the hard disk status or reinstalling the system.
About GE Logiq C5 Motherboard
- Core processor and computing power:
GE LOGIQ C5 motherboards may be equipped with high-performance processors or processor groups to ensure that real-time processing of ultrasound images and complex image processing algorithms can run efficiently. This high-performance computing capability is essential to support the multiple imaging modes and advanced features of the LOGIQ C5 system. - Signal processing capabilities:
The motherboard integrates advanced signal processing circuits to receive and process weak electrical signals from ultrasound probes. These signals are amplified, filtered, and digitized into data that can be used to generate ultrasound images.
Other GE related ultrasonic components we can offer:
Brand | System | Description | Part Number |
GE | Logiq P5 | APS Power Supply | 5140505/5166108/5329667 |
GE | Logiq P5 | CPU mainboard | 5168431 |
GE | Logiq P5 | SYSCONPM | 5177848-3 |
GE | Logiq P6 | CPU Mainboard | |
GE | Logiq P6 | PST Power Supply | 5245004/5244555 |
GE | Logiq P6 | SYSCONML | 5252326-3 |
GE | Logiq S7/Logiq S8 | CPS Power supply | 6626600 R02/5413249-3 |
GE | Logiq S7 | BF128 transmitting board | 5392446 |
GE | Logiq S7 | GFS board | 5371196 |
GE | Logiq S8 | BF192 Beamformer | 5357234-2 |
Brand | System | Description | Part Number |
GE | Logiq E9/vivid E9 | GTX | GA200726 |
GE | Logiq E9 | MRX Board | 5393908/5393912 |
GE | Logiq E9/vivid E9 | GFI2 | 5161631 |
GE | Logiq E9 | BEP Power Supply | 5393800-3/5166790-2 |
