GE RIC5-9A-RS Ultrasound Probe Repair

● Model: GE RIC5-9A-RS

● Compatibility: GE Logiq E9; GE Logiq P9; GE Logiq S7; GE Logiq S8

Fault Phenomenon: The cable is aging and broken, the strain relief is aging, the connector housing has wear marks, the done is slightly damaged, the image on the machine is seriously missing, the crystal array is broken. And there has interference if shake the cable, and the image is missing, the cable is broken.

Suggestion: Replace the cable, strain relief, connector housing, lens and crystal array.

60 days warranty, test video/picture will be provided

product details

Warnings and cautions of ultrasonic probe

★ The ultrasonic probe is a valuable device. It must be careful in the process of use. Avoid dropping, impact, or abrasion to transducers.

★ When installing or removing the probe, first switch off the power and then operate it carefully.

★ Avoid rapid and extreme temperature changes, as well as lengthy exposure to direct sunlight or a strong ultraviolet light source.

★ Do not use sharp objects to penetrate the acoustic lens.Once the acoustic lens is damaged, the coupling gel is easy to enter the interior of the probe and damage the piezoelectric element.

★ Do not soak transducer in any liquid above the recommended level as stated in the user manual for your system, please operate according to the manufacturer's instructions, otherwise it will lead to circuit failure or even burn out.

★ Do not disinfect at high temperature, because the probe is equipped with piezoelectric ceramics, high temperature will weaken the effect.

★ Before use, carefully check whether the housing and cable are damaged, so as to prevent the probe from high voltage injury.

★ After the probe is used, the residual coupling gel on the probe must be wiped clean to prevent rats or other animals from gnawing the lens.

Common ultrasound Probe Damage(Specialty 3D/4D Volume probes)

Common ultrasound probe damage	Solutions
Lens cap damage	Lens cap replacement
Fluid and oil leaks	Lens cap replacement, oil reservoir repair and replacement
Cable cuts	Cable patches, possible cable replacement
Inoperative steering	Motor repair
Connector housing electrical damage	Minor electrical repairs, pin module replacement
Weak or dead elements, dropouts in an image	Array ball replacement, oil reservoir repair and replacement

Part of hot GE probes we can repair

GE	C1-5-D
GE	C1-5-RS
GE	4C
GE	4C-RS
GE	4C-A
GE	4C-D
GE	4C-SC
GE	E8C/E8C-RS
GE	E8CS
GE	RIC5-9-D
GE	3CRF-D
GE	C1-6-D
GE	RAB4-8-RS
GE	RAB2-5-RS
GE	6S-RS
GE	12L-RS
GE	3SC-RS
GE	L6-12-RS
GE	11L
GE	11L-D
GE	12L-RS
GE	8C
GE	3S
GE	3S-RS
